SAMSUNG Hanwha Auto Tray Feeder Unit-STF200S
SAMSUNG
STF200S
Specification
Outline Dimension(mm): W1612*L930*H1945(Top of the signal light)
Weight: Max 250KG
Available Tray Size(mm): Max:323*136/ Min: 200*100
Magazine: 1 Tray, 20 pallets ,1 Magazine: Tray feeder
Volt: Single phase AC 100V/110V/120V/200V/220V/240V
Power: 1000VA MAX,300VA RMS
Max. Height of componenet Supplied: 9.5mm,25.4mm option: load the trays on every other stage
Noise: 75db
UI：Monitor: 7 inch TFT LCD. Operation: Touch Pad, OS: Windows CE EMBEDDED. Language: English
