TA-R YSM40R
YAMAHA
YSM40R
| Z:TA-R YSM40R 4-Beam,4-Head Spec.(YSM40R-4) | |
| Applicable PCB | L700xW460mm to L50xW50mm |
| Mounting capability(under optimum conditions as defined by Yamaha Motor) | 200,000CPH(When using RS head) |
| Applicable components | Ultra-High-Speed (RS) Head: 0201mm* to □6.5mm (Height 2.0mm or less)*option |
| Multi (MU) Head: 03015mm to 45×60mm (Height 15mm or less) | |
| Mounting accuracy(Under optimum conditions as defined by Yamaha Motor when standard evaluation materials are used) | +/-35μm(25μm)Cpk≥1.0 (3a) |
| Number of component types* 8mm width tape conversion | Max. 80 feeders with RS headsMax. 88 feeders with MU headsMax. 84 feeders with RSx 2 + MU x 2 heads |
| Power supply | 3-Phase AC 200/208/220/240/380/400/416V +/-10% |
| Air supply source | 0.45MPa or more, in clean, dry state |
| External dimension | L1,000xW2,100×H1,550mm(excluding projections) |
| Weight | Approx. 2,100 kg |
